AZ Patio Heaters and Replacement Parts

• Propane use only
• Flow Capacity: 0 - 50,000 BTU/Hr

• Inlet Pressure: 25 - 250 PSIG

• Outlet Pressure: 11"W.C.

• Certification: CSA


• 3/8" OD Natural Gas Ext.Hose
• Inlet 3/8-18NPT
• (3/8"QDD Set)x5/8-18 UNF Swivel Nut
• 60,000BTU Capacity
• Certified: CSA
• 20ft Hose

• Propane use only
• Flow Capacity: 0 - 85,000BTU/Hr

• Inlet Pressure: 25 - 250PSIG

• Outlet Pressure: 11"W.C.

• Certification: CSA


• 12' Natural gas hose.
• Flexible high pressure line.
• Quick-disconnect.
• 3/8 thread.

** Note: Quick connect hoses cannot be connected together unless you purchase Male to Male union. This part can be found at all major hardware stores in your area. Part Size: 3/8" Flare x 3/8" MIP.

• Pan: 18"
• Burner: 12"
• Regulator: RYQB01(hose length 48")
• Valve: BS190
• Thermocouple: 24"
• One outlet ignitor
• Ignition electrode assembly

• Portable adapter hose.
• 10' long.
• Adapts a 20lb propane tank to a 1lb connection.
• Extends the life of your tabletop heater.
• Also works for camping stoves and portable appliances that require a 1lb propane tank.

• Portable adapter hose.
• 5' long.
• Adapts a 20lb propane tank to a 1lb connection.
• Extends the life of your tabletop heater.
• Also works for camping stoves and portable flames that require a 1lb propane tank.

• Use for Appliances with Type 1 Connections
• Working Pressure: 250PSI
• Working Temperature: -40 Degress Celsius~55 Degree Celsius
• Inlet Thread: 0.885"-14UNS-LH. Built-In Leak Detector
• Certificate: ETL

• Aluminum reflector shield
• Included: 3 outer panels and 1 center panel.
• Hardware to assemble shield.
• 33" assembled diameter
• Center Piece Mounting: 6 7/8" from hole to hole to attach to the main burner screen.
• 3 holes for mounting.

*** MOST COMMON APPLICATION***

Will fit Garden Treasures heater model 328157 and 48650 sold at Lowes in 2010 to 2015.

Will fit t models: HSS-A-SS, HSS-A-GH, GS4400BK, GS4400GD, GS4400SS, HLDS01-, PH01 models,

• Tall Glass Tube Patio Heater replacement tube 4"D x 49.5" tall.
• ***The single tube will also fit models that come with a two-piece tube***
• Reference Part number: 584736, 639564, PH08, HLDS01-GTHG, HLDS01-GTSS, HLDS01-GTPC, BFH-A, NG-GT-BRZ
• Rubber ring not included.
• PLEASE MEASURE ACCORDINGLY. THIS WILL ALSO FIT SOME 2014 AND NEWER MODEL 3-SIDED HEATERS.

• Tall Glass Tube Patio Heater replacement tube 4"D x 49.5" tall. Each piece measures 24.75" in length.
• Stability conncetor ring not included.
• Reference Part number: 584736, 639564, PH08, HLDS01-GTHG, HLDS01-GTSS, HLDS01-GTPC,
• Rubber ring not included.
• PLEASE MEASURE ACCORDINGLY.

• Pressure regulator.
• Regulates your propane for an adequate burn.
• Used with heaters 2008 or newer.
• Male end connects directly to main gas line.
• Female coupler attaches to propane cylinder.
• 250 psi

Will fit Garden Treasures heater model 328157 and 48650 sold at Lowes in 2010-2013.

Will fit Home Depot models: HSS-A-SS, HSS-A-GH, GS4400BK, GS4400GD, GS4400SS

• Complete regulator and gas feed line ( 2008 and newer ) Most Common
• Gas feed line 5'
• Regulates your propane for an adequate burn.
• Used with heaters 2008 or newer.
• Female end connects directly to main burner.
• Female coupler attaches to propane cylinder.
• 250 PSI and 11 W.C.
• Most common regulator for all firepit burners.

*** This hose and regulator has a standard 5/8" Female compression fitting which connects to burner head.

Used on models: HLDS01-, HSS-, Hiland and Primeglo

Will fit Home Depot models: HSS-A-SS, HSS-A-GH, GS4400BK, GS4400GD, GS4400SS

Will fit (ACE) Living Treasure outdoor patio heater model # 4526190

• Tall Heater Thermocouple
• Sensor activates main control valve after pilot light is lit.
• Allows the main gas to be released.
• 2 connectors for attaching to an anti-tilt device.
• 18 in long.
• M8 (metric) connection.

**Will also fit Glass Tube Heater sold by Home Depot SS-GT BFC-A-SS

• Complete burner for tall patio heaters with 2 1/2" Pole .
• Piezo striker.
• Control knob.
• Emmitter Screen 3 post
• Main control valve.
• Pilot assembly.
• Diffuser plate.
• Gas supply line and regulator included for easy application.
• Made for a 2 1/2" pole. (Pole connection hardware included)
• Can be used for 2" pole if you use your old burner coupler to convert.

• 10 3/4" diameter
• 8" Tall
• 3 threaded holes to attach reflector shield. 6 7/8" apart
• Stainless Steel.
• 4 mounting holes for attaching to valve body.
• Hardware not included.

Will fit Home Depot models: HSS-A-SS, HSS-A-GH, GS4400BK, GS4400GD, GS4400SS, ALSO FITS FIRE SENSE PATIO HEATERS

• Mechanical style anti tilt switch.
• 2009 heaters or newer.
• For safety, if heater tips or falls over, this device will automatically shut your heater off.
• Can be used in Garden Treasures heater model 48650, 48221, 328154 and 328157 sold at Lowes in 2010 to 2015.
• Connected through your thermocouple leads.

*** MOST COMMON APPLICATION***

Will fit models: HSS-A-SS, HSS-A-GH, GS4400BK, GS4400GD, GS4400SS, HLDS01-models, HLDS032-models, PH08 and PH01 models.

• Tall Patio Heater Cover
• 210 D Strong Durable Oxford
• Protect your investment from the elements.
• Zipper for easy opening and installation.
• Shield- 34"D round, Base-19x19" Round, Height- 89"

*** Limited Quantities***

• Square Glass Tube Heater Cover
• 210 D Strong Durable Oxford
• Protect your investment from the elements.
• Zipper for easy opening and installation.
• Shield- 19"x19" square, Base-21x21" square, Height- 91"

*** Limited Quantities***

• Umbrella base electric heater
• Umbrella fits into top of the unit
• Balance weight included
• 110-120V, 60Hz
• 1500 Watts
• 14" x 14" x 31"
• IP55 rated

• New Pilot assembly comes with thermocouple, venturi tube, igniter stem, and igniter wire.
• Application for Tall Square Commercial Heater
• Igniter wire and thermocouple wire's are a total of 22" long
• Pilot feed tube is not included.
